Project 5

Overview

In this project, there are three parts.

• Part 1: Inverting the Generator: Reconstruct the image from a given latent code.
• Part 2: Sketch to Image: Generate a photo from a given sketch.
• Part 3: Stable Diffusion: implement SDEdit to edit a given photo with a text prompt using DDPM.

Part 1: Inverting the Generator [30 points]

(1) Combinations of the losses

In part 1, my loss function is a weighted sum of L1, L2, and perceptual losses. All following results are produced after 1000 iterations, with stylegan in w+ space. I tune the weights for a best configuration.

Original data

Loss Comparison (Varying Perceptual Loss Weight)

Perceptual loss weight	L1 Loss (L1=10, L2=0)	L2 Loss (L1=0, L2=10)
0.001
0.01
0.1
1.0

Observation:

Based on these experiments, I found that using a small perceptual loss weight (0.1) with L2 loss weight of 10 and no L1 loss produced the best results. This combination can recover the cat with more details such as the fur texture, the eyes, and the facial features. It is also noticeable that the purple background on the left up corner is more vivid.

(2) Different generative models

Using the perceptual loss weight of 0.001 and L2 loss weight of 10 and 1000 iterations, I compared the reconstruction quality between vanilla GAN and StyleGAN in z space.

Model	Result
Original data
Vanilla GAN
StyleGAN

Observation:

StyleGAN result is much better than vanilla GAN. The StyleGAN result preserves more details in the cat's fur texture and facial features, while the vanilla GAN result appears more blurry and loses some fine details.

(3) Different latent space

Using StyleGAN model with the perceptual loss weight of 0.001 and L2 loss weight of 10 and 1000 iterations, I compared reconstructions in different latent spaces (z, w, and w+).

Latent Space	Result
Original data
z space
w space
w+ space

Observation:

The w+ and w space results are slightly better than the z space result. The w+ space reconstruction shows the most accurate color reproduction, particularly in the fur color. It also preserves sharper features in the cat's face, especially around the eyes and mouth. The w space result is similar but slightly less detailed, while the z space result appears more blurry and loses some of the fine details.

Run time:

All the experiments are 1000 iterations and take ~30 seconds to run on a Nvidia A6000 GPU.

Part 2: Sketch to Image [40 points]

In this part, I used StyleGAN's w+ space with the parameters (perceptual loss weight = 0.001, L2 loss weight = 10, iterations = 1000) to generate realistic cat images from hand-drawn sketches. This is achieved by optimizing a random noise image to match the sketch in masked regions while maintaining the natural image manifold of the generator.

Sketch	Mask	Result

Observation:

• The color that are not common in the cat like grey are not generated well.
• Sparse masks produced more varied results as less pixels are constrained.
• Adding more details in the sketch also contributes to more realistic details, especially in the cat's eyes and facial features.
• Higher contrast in the sketch also produces results with sharper features.
• Under W+ space, the results from similar sketches tend to converge to similar cat images.

Part 3: Stable Diffusion [30 points]

I implemented the SDEdit approach by incorporating an input image along with a text prompt to guide the diffusion DDPM process.

(1) Parameter Study

I conducted a parameter study on classifier-free guidance strength and timestep to understand how different timesteps and guidance strengths affect the output quality:

		Timestep
		500	600	700
Guidance Strength	15
	25
	35

Another example

		Timestep
		500	600	700
Guidance Strength	15
	25
	35

(2) Different amounts of noise added to the input

I conducted a parameter study on the amount of noise added to the input to understand how different amounts of noise affect the output quality:

Observation:

If the noise std is small, the editing is closer to the original sketch.

If the noise std is large, the editing is more varies, and too much noise can lead to the image looking fake and noisy.

Bells and Whistles

(1) Interpolate between 2 latent codes

Below is the interpolation between the 0th and 1st data and the 2nd and 3rd data in cat dataset.
