| The large rock seen in the background of this image is Yogi. The front right rock has been plowed by the rover, and deformation by the rover wheel is evident. | The same rock seen at lower right in the previous image is seen here with a rover wheel in the foreground for comparison. | This area of soil in front of Yogi will be investigated by the Alpha Proton X-Ray Spectrometer. | This image of Yogi was taken in poor lighting conditions. Scientists have planned to image Yogi in better light in order study its texture close up. |
| This red color image of the rover wheel was taken prior to soil mechanics tests. | This is a red-color image of the rover wheel and the indentation that the wheel has made on the soil. | The APXS is shown in the end of Sol 4 image of the rover placed against the soil at the base of Yogi. | A portion of the color "monster panorama" showing the front (or left) ramp and part of the low-gain antenna. |
| Here we see Wedge and Flat Top imaged in color as part of the "monster panorama". | A color version of the image of the rover as it left the rear (or right) ramp. | Yogi in the background of the image. The light colored rim of material in front of Yogi may possibly be evaporation deposits from ancient water puddled on the surface. | In the foreground are the airbags, and to the left are more hypothesized evaportion deposits. |
| Casper, the light colored rock in the middle left of this image, is a prime target for the APXS. The disturbed soil in the lower right of this image was caused by the retraction of the airbags. | Rocks and intersting textures of the Martian surface are imaged above. | The large rock to the upper right of the airbags in this image, appears to be riddled with many cracks. | The Atmospheric Structure/Meterology Instrument mast is standing straight up in this image. The wind socks are hanging vertically, indicating that the winds are light. ASI/MET scientists report that winds measurements have yet to exceed 10 mph. The apprent offset of the mast in this image is caused by parallax. |
